RA-DC8020
Product description：
DC motor powered axial fan series covers a diameter range of models from 20mm to 200mm. with maximum air volume up to 700 m3/h and maximum static pressure up to 500 Pa. Input power sources for DC series are 12VDC 24VDC 48VDC; DC motors make excellent performance of this product Low noise Low vibration Energy saving Enviromental performance quietness. The product series is RoHS compliant and is also certified according to many quality management accreditation systems and has gained various accreditations such as UL TUV and VDE. Every model undergoes rigorous testing to achieve minimum noise under high airflow and air pressure conditions. All models are meet strict reliability requirements.

Data Sheet
Detailed Parameters
Model No. & Category

Model No.
RA-DC8020

Product Types
Axial Fan

Product Types
Brushless DC Motor


Basic Parameters

Model:
Voltage  (V)
Current  (A)
Power（W）
Speed（RPM)
Pressure (Pa)
Air Flow（m3/h）
Air Flow（CFM）
Noise  (dB）

12L
12
0.1
1.2
2500
23
37
22
30

12M
12
0.14
1.7
3000
32
45
26
34

12H
12
0.19
2.3
3500
40
50
30
38

24L
24
0.06
1.4
2500
23
37
22
30

24M
24
0.09
1.7
3000
32
45
26
34

24H
24
0.12
2.9
3500
40
50
30
38

Customized
√
√
√
√
√
√
√
√


Product Information

Bearing Type
Ball OR Sleeve

Impeller and Fram
PBT PLASTIC

Approvals
UL CE CCC

Speed Control
PWM VSP Temperature Control Fix Speed with Pressure Intermittent

Protected
Lock Auto-start Overload

Out Signal
FG RD LD

Insulation Class
B

Insulation Resistance
10MΩ/500V DC

Dielectric Strength
2Min/500V AC/5mA

Insulation Class
F

Relative Humidity
20%-85%

Working Temperature
-10℃/+60℃

Max Life
80000 hours
